Adjusting the input gain
Adjust the volume of the input sound from the microphone input jack and line input jacks. Use the gain control knobs (GAIN) to make these adjustments.
-
While outputting sound from the microphone or instrument, turn the gain control knobs (GAIN) to the left and right to adjust the volume.
- Turn a knob to the left to decrease the volume and to the right to increase the volume.
Indicator lamps
- When the level of the sound output to a device is −15 dBFS or higher, the signal indicator lamps (SIG) light in green.
- If the peak indicator lamps (PEAK) light frequently, decrease the gain to the point that the lamps light only for an instant at the maximum input.
- Input peak indicator lamp
- Signal indicator lamp
- Output peak indicator lamp
